CRL Jackson Adjustable Spring Power Multi-Size 90º Hold-Open Extended Spindle Overhead Concealed Door Closer Bode Only - REPLACEMENT PART 20104M20
C.R. Laurence CRL Jackson Adjustable Spring Power Multi-Size 90º Hold-Open Extended Spindle Overhead Concealed Door Closer Bode Only - REPLACEMENT PART 20104M20  | 2033020EXT
Category: Jackson Adjustable Spring Power Overhead Concealed Closer Body Only
CRL Jackson Adjustable Spring Power Multi-Size 90º Hold-Open Extended Spindle Overhead Concealed Door Closer Bode Only - REPLACEMENT PART 20104M20
SKU: 2033020EXT
UPC:

$218.09 (20% off)

$181.74

Product Details:

Adjustable Spring Power Size 1 to 4 Closer Body
Longer 7/8" Spindle Required for Use with Patch Fittings and Rail Hardware
Will Retrofit Similar Fixed Size Overhead Concealed Door Closers

Door Closers Cross Reference Chart

This CRL Jackson Adjustable Spring Power Overhead Concealed Door Closer is available for A.D.A. barrier-free applications and features a longer spindle (approximately 7/8 in (22 millimeter)), the preferred length when used in conjunction with Patch Hardware Fittings.
The closer is adjustable in a range of sizes 1 through 4, allowing the spring power to be adjusted for both interior and exterior doors as needed.
This closer will easily retrofit similar fixed size Overhead Concealed Door Closers.

Closer Body Length: 11-5/8 in (295 mm)
Closer Body Width:   3-11/16 in (94 mm)

Minimum Order: 1 Each

Important Note:
Mounting clips are not included with this closer body.
