Product Details:

Large range of anchor rod diameters (3/8" - 1-1/4")
Features a chisel tip for use with the HVU system
Head marking for easy verification of steel grade and rod length, even after installation
Chamfered end ensures easy threading of the nut
Free of oil and other contamination for highest performance with HIT adhesive anchoring systems

Applications: Suitable for fastenings in concrete and other base materials in combination with the relevant Hilti HIT injectable adhesive mortars. Suitable for fastenings in concrete with Hilti HVU capsules.

Anchor size: 7/8 in
Anchor length: 10 in
Outside diameter: 7/8 in
Material composition: Steel, strength 5.8 grade, zinc-plated (min. 5 µm)
Environmental conditions: Indoor, dry conditions
Head configuration: Externally threaded
Type of fixing: Pre-fastening
Wrench Size: 1-1/4 in

Package Quantity: 10 Pieces

Hilti PN: 385440
