Category: CRL OP50 3/4" Offset Aluminum Pivot for 1/8" Recessed Doors
CRL Offset Duranodic Bronze Left Hand Pivot Set 1/8" Recessed
SKU: 0P50LHDU
UPC:
Product Details:
Commonly Used On Arch Aluminum Type 1/8" (3.2 mm) Recessed
Doors
Handed - Not Reversible
1/8" (3.2 mm) Vertical Adjustment
The CRL Offset Handed Pivot Set 1/8" Recessed
is commonly used on Arch Aluminum doors recessed 1/8 inch (3.2
millimeter). Suitable for aluminum frames and doors weighing up to
125 pounds (57 kilograms), the matching contemporary design will
complement any other comparable door system.
Color: Bronze
Minimum Order: 1 Set
Additional Product Information:
This pivot is handed and non-reversible. Vertical adjustment can be
made up to 1/8 inch (3.2 millimeter) without removing the door. The
fully retractable spring loaded hardened top pin makes for easy
door installation and adjustment. An oilite bronze bushing is
standard for the top frame portion and full race bearing in the
bottom door portion.
