Product Details:

Self-Centering with Reversible 5º Pivot Pin
Available in Several Beautiful Finishes
135 Degree Glass-to-Glass Standard Model

These new CRL Geneva 045 Series 135° Glass-to-Glass Hinges are used in conjunction with the appropriate Geneva Pony Wall Mount Hinge for a 135° angle. Geneva Hinges are self-centering, and contain a reversible 5° Pivot Pin. In addition, Custom Pivot Pins are available to accommodate "off angle" installations. Made of solid brass with all moving parts (pins and springs) in stainless steel.

Color: Oil Rub Bronze

Minimum Order: 1 Each

Additional Product Information:
Standard Reversible Pivot Pin: Each Geneva Hinge contains a Reversible Pivot Pin. One side of the Pin is marked 90º. The opposite side is marked 85º. Standard Geneva Hinges come with the 90º side activated. Offset Models come with the Pin pre-set to 85º (5º tighter closure into shower interior). The Pin can be rotated (not flipped upside down) to activate the other side.

Specifications:
Glass Thickness: 3/8 to 1/2 inch (10 to 12 millimeter) tempered safety glass. There are many standard finishes, and custom finishes that are available upon request. Templates specific to the GEN045 Hinges are packed in each box.
