Product Details:
- Heavy-Duty Glass Gate with Cap Rail
- Beautiful in Design and Functional in
Operation
- Pivots on Ball Bearing Pivot at the Top and Floor
Closer at the Bottom
|
We have developed the CRL Swinging
Gate for commercial use with our HRS Glass Rail System. The
gate is an offshoot of our Wedge-Lock Door Rail
System. The bottom rail is widened so it matches the width of
the adjacent fixed railing Base Shoe. The upper patch
fitting is modified to allow for mounting to the stainless steel
wall bracket and the modified Cap Rail. The top of the gate pivots
on a heavy-duty ball bearing, while the bottom pivots on a floor
mounted commercial door closer. The floor closer always returns the
gate to the closed position, and the closing speed is
adjustable.
- Gate Can Be Adjusted In and Out at Both the Top and the
Bottom
- Standard Gates are 35-3/4 inches (908 millimeters) Wide with a
three inch (76.2 millimeter) Cap Rail, and a Widened Bottom Rail to
Match the Adjacent Base Shoe
- Maximum Gate Size is 42 inches (1067 millimeter) wide by 60
inches (1524 millimeters) High
- Custom Fabrication is Also Available
All Swinging Gates are custom fabricated to your specifications.
The unit above was mounted to a four inch (101.6 millimeter) square
steel post, set in concrete with machine screws. This is important,
because the tight clearances used in the installation require the
gate to be rigidly mounted. Also under development is a new
freestanding post model. For more information or a quote on
Swinging Gates, contact us at (888) 663-9830 in the U.S., (877)
421-6144 from Canada, or (323) 588-1281 (International). Ask for
Extension 7730, or contact us
here.
