Product Details:
- Straight Shank Drill
- Designed For High Volume Glass
Fabrication
- A Full 3/8" of Diamond Matrix Depth
|
CRL PD Series Metal Bond Diamond
Drills use a special diamond and brass bond for
maximum performance in glass. Metal bond drills offer the greatest
life, 1000 to 2000 holes in 1/4 inch (6.4 millimeter) glass with
proper maintenance and the use of a wet Sharpening Stone to expose fresh
diamonds, of any type of diamond drill. PD Series
Diamond Drills use a special diamond and brass bond
for maximum performance in glass drilling. These Italian made
multi-layer drills cut faster and run cooler than any other drill
on the market. They have a full 3/8 inch (9.5 millimeter) deep
cutting surface filled with diamonds and bronze bond, which allows
for long drill life, but also makes this style drill more fragile.
They should always be used in true running machines on flat glass
surfaces. The CRL PD Series Drill can be
used in portable drill machines such as the CRL2, but is specially suited for
production equipment like a shop drill press. This diamond drill
features an extra long 1-3/8 inch (35 millimeters) by 3/8 inch (9.5
millimeter) diameter shank for a positive grip on the drill.
Always wear the proper safety gear including gloves and eye
protection when drilling glass. Work should be performed on a flat,
horizontal surface. A Ground Fault Circuit Interrupter must be used
when using any type of electric tool in conjunction with water or
coolant. Failure to follow any of these precautions can result in
operator injury.
- Overall Length: 3-3/4 in (95.3 mm)
- Recommended RPM: 4000 - 6000
